From the 1Department of Orthopedic Surgery, University Hospital Aachen, Pauwelsstraße 30, 52074 Aachen, Germany, 2Department of Orthopedic Surgery, Klinikum Wels-Grieskirchen, Wels, Austria and 3Department of Orthopaedics and Traumatology, Alexandria University, Alexandria, Egypt.
Objective: To investigate the effectiveness of modified rehabilitation programmes in comparison with standard rehabilitation programmes after total knee arthroplasty through randomized controlled trials.
Data sources: A search was conducted in PubMed, PubMed Central (PMC) and Cochrane Library databases in December 2020.
Study selection: Randomized controlled trials were reviewed if they compared a physiotherapy exercise intervention with usual or standard physiotherapy care, or if they compared 2 types of exercise physiotherapy interventions meeting the review criteria, after total knee arthroplasty for osteoarthritis. A total of 18 randomized controlled trials were included at the end of the screening process.
Data extraction: Two authors independently screened the literature, extracted data, and assessed the quality of included studies. The outcomes were knee extension, knee flexion, pain visual analogue scale, overall Western Ontario and McMaster Universities Osteoarthritis Index (WOMAC), 6-minute walking test, and Timed Up and Go test.
Data synthesis: There was no clear pattern regarding which combination of starting time-point and duration of the rehabilitation programme after total knee arthroplasty significantly improves the clinical outcome when comparing modified rehabilitation programmes with standard programmes. Moreover, no particular modification to the modified programmes could be solely attributed to the improved clinical outcome in the 2 studies that showed significant improvement.
Conclusion: Modified rehabilitation programmes do not result in systematic improvement in clinical outcome over one-size-fits-all-approaches after total knee arthroplasty.
Key words: rehabilitation; exercise; physical therapy; total knee replacement.
ccepted Mar 23, 2021; Epub ahead of print Apr 13, 2021
J Rehabil Med 2021; 53: jrm00200
Correspondence address: Waleed Alrawashdeh, University Hospital RWTH Aachen Pauwelsstraße 30, 52074 Aachen, Germany. E-mail: firstname.lastname@example.org
The aim of this study was to compare modified rehabilitation programmes with standard rehabilitation programmes after total knee replacement. A total of 18 randomized controlled trials were included at the end of the screening process. Six clinical outcomes were used for comparison. To our knowledge, this is the first study to compare modified and standard rehabilitation programmes based on the starting point and the duration of each programme. The results of the comparison showed that there is no clear pattern in the combination of starting time-point and duration of rehabilitation that significantly improves clinical outcomes. Moreover, improved clinical outcomes could not be attributed solely to any particular modification to the programmes. Accordingly, a one-size-fits-all approach to modified rehabilitation programmes does not result in systematic improvement in clinical outcome.
Total knee arthroplasty (TKA) is an established standard procedure to alleviate problems caused by advanced knee osteoarthritis (OA) (1). The annual worldwide incidence of TKA has increased steadily over the past 2 decades (2). The incidence of TKA in industrialized countries is 150–200/100,000 inhabitants (3).
After TKA, the patient’s movement is limited and restricted due to decreased muscle strength. For instance, muscle function has been found to be reduced by 20–25% at one month post-TKA (4), while, after one year, it remains lower than in healthy adults, with reports of 18% slower walking speed and 51% slower stairclimbing speed (5). Furthermore, range of motion (ROM) of the knee joint is reduced due to post-operation pain (6), haematoma and swelling (7). These limits complete functional recovery to only 67% of patients (8). In addition, the strength of the quadriceps muscle is reduced by 30.7% immediately after TKA, and by 50–60% after one month, despite the initiation of rehabilitation within 48 h after surgery (9).
Postoperative rehabilitation programmes are therefore of the highest importance, because they can improve function, outcome, and mobility in patients after TKA (10). These programmes consist of fitness components comprised of exercises for joints and muscles that include ROM, strength, walking, function, endurance, and balance. Regaining full ROM is essential to restore the natural capacity of movement that assists in regaining muscle strength by allowing full muscular contraction. Walking and functional exercises improve blood circulation and enable the ability to perform activities of daily living, such as standing, sitting, and stair climbing, to be regained (11). Endurance and balance exercises support the previous fitness components by increasing the duration of exercises and stability. An increase in endurance will enable subjects more time to exercise and to derive more benefit from exercises. Furthermore, improved balance will help patients to perform the exercises safely and smoothly, especially with exercises that require them to switch between legs. Regaining all these components is essential to reaching full recovery following a TKA.
In the clinical setting, post-operative rehabilitation programmes differ concerning the starting time-point and duration. Different arguments have been brought forward to support the diverse approaches; however, to date, the benefits of these approaches have not been directly investigated in a clinical setting. The lack of a universal definition of starting time-points and duration spans adds further complexity. Therefore, it is important to analyse whether a particular combination of starting time-point, and duration is more beneficial. Furthermore, since additional methods are being incorporated into modern rehabilitation programmes, it is worthwhile analysing whether these modifications improve the clinical outcome and prognosis and, if it is the case, which methods or exercises yield the best clinical improvements.
Therefore, the aim of this systematic review and meta-analysis of randomized controlled studies was to evaluate the effectiveness of different modified rehabilitation programmes vs standard care after TKA, and the effects of starting time-point and duration.
A search of Medline (PubMed), PubMed Central (PMC) and Cochrane Library databases was conducted. Exploded MeSH terms and keywords were used to generate sets for the following themes: total knee arthroplasty, total knee replacement, osteoarthritis, and rehabilitation approach. The Boolean terms “AND”, “OR” were used to find their intersection. Limitations were used, including English language publications between 2000 and 2020 and randomized control trial. In addition, the reference lists of all included studies were reviewed (see Appendix SI for complete search strategy and results). Furthermore, the outcomes were categorized and analysed for ROM (flexion-extension), pain visual analogue scale (VAS), Western Ontario and McMaster Universities Osteoarthritis Index (WOMAC) questionnaire, 6-minute walking test (6MWT), and Timed Up and Go test (TUG). Comparisons were made between outcomes in the final assessment for each group.
The review was conducted using standard methodology outlined in the Cochrane Handbook (12) and the findings were reported according to the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) statement guidelines (12).
Before beginning the systematic review and meta-analysis, a protocol was written outlining the search strategy, inclusion and exclusion criteria and outcomes of interest. Eligible studies were chosen based on the following criteria:
Examination of post-operative effect of the rehabilitation programme using physical rehabilitation methods (studies using music, medication, and supporting devices, such as knee-braces, were excluded).
Patients underwent unilateral or bilateral knee arthroplasty, since both surgeries have similar rehabilitation programmes.
Studies applied only to a post-operative rehabilitation programme.
Studies included a randomized design comparing a standard-based rehabilitation programme with a patient-modified programme.
Standard rehabilitation programmes must have contained at least 3 of the following 4 fitness components: strength, ROM, function and walking.
Studies calculated the mean and standard deviation (SD) of the parameters the studies measured.
Studies had to be published in English language.
Two authors (WA, BR) independently assessed the risk of bias of the articles selected for detailed review. Methodological domains of the assessment, namely randomization sequence, allocation concealment, blinding, and conflicts of interest were graded according to the PEDro scale checklist (13) .
Two authors (WA, BR) independently extracted the data from the included articles in forms; previously pilot-tested for feasibility and comprehensiveness. Data were extracted from each trial regarding participants (age, sex, group size), the content of the intervention (number of sessions, tools, and tests they used, standard care vs modified care or modified vs modified), setting and timing (starting point, duration), type of surgery and outcome. When a trial employed 2 variations in rehabilitation interventions, only one group was included (14–16).
For outcomes reported as continuous variables, mean and standard deviation were extracted. Outcomes with mean and confidence interval, or medians, and interquartile ranges were excluded.
For statistical analysis, Review Manager Software 5.3 (The Nordic Cochrane Collaboration, Copenhagen) was used. For continuous data, the inverse variance with arithmetic mean was considered. For dichotomous data, the Mantel-Haenszel method with odds ratio (OR) was considered. To evaluate heterogeneity, both χ2 and I-square (I2) statistical tests were performed. Value of χ2 > 0.5 along with I2 > 50% indicated heterogeneity. A fixed-effects model was used. If heterogeneity significantly affects the comparison, a random-effects model was used. The confidence interval (CI) was set at 95%. Values of p < 0.05 were considered statistically significant.
Defining the groups
The study defined the standard programme as control group based on the description of the rehabilitation programme in the RCTs; each study at least had to include 3 out of 4 fitness components (ROM, strength, walking or function) in the standard programme during the rehabilitation period. The experimental group was defined as the group that used the additional method plus the above-mentioned fitness components. The studies were categorized based on 2 factors commonly known to affect the outcome of the rehabilitation programmes: the starting time-point and duration of the rehabilitation programme. Accordingly, the studies were subdivided into 4 rehabilitation intervals: (i) early and short, (ii) early and long, (iii) late and short, and (iv) late and long. The interval subdivision of the studies between early and late rehabilitation was based on the wound-healing phases. After TKA the wound will be in the inflammatory phase between 4 and 6 days (17), which is a natural response to surgery. The signs elevate in the surrounding skin in exudate levels, erythema, heat, oedema, pain and functional disturbance (18). Some healthcare practitioners wait until the inflammation disappears before starting the rehabilitation programme, while others prefer to start within that phase, arguing that rehabilitation exercises boost the anti-inflammatory response and, thus, accelerate recovery. Therefore, in this review, the starting time-point factor was determined “early” when the rehabilitation programme started within the first week, while programmes that started after that time-point were considered as “late” starting programmes. There were 13 studies that started early (14–16, 18–27), while 5 studies started late (28–32). As for the duration factor, there is a lack of uniform criteria to define the length of the programme. In Germany the in-house rehabilitation programme has a maximum duration of 3 weeks. Accordingly, and for the sake of having a uniform anchor point, programmes that ran for less than 3 weeks were considered as “short” and programmes that ran more than 3 weeks as “long”. Nine studies employed short programmes (14–16, 18–23), while 9 studies employed long programmes (28–32).
When cross-checking the 2 factors, 8 studies started early and had a short duration, 4 studies started early and had a long duration, no studies started late and had a short duration, and 5 studies started late and had a long duration (Table I).
Table I. Analysis of studies that used post-total knee arthroplasty rehabilitation programmes
The initial search identified 267 potentially relevant studies. After reviewing titles and abstracts and applying the inclusion and exclusion criteria, only 18 articles (Bade et al. 2017 (26), Beaupre et al. 2001 (14), Bruun-Olsen et al. 2009 (18), Demircioglu et al. 2015 (27), Denis et al. 2006 (15), Ebert et al. 2013 (24), Hardt et al. 2018 (23), Jakobsen et al. 2014 (28), Labraca et al. 2011 (19), Lastayo et al. 2009 (29), Lenssen et al. 2006 (20), Lenssen et al. 2008 (21), Liao et al. 2013 (30), Mau-Moeller et al. 2014 (22), Piva et al. 2017 (37), Rahmann et al. 2009 (16), Schache et al. 2019 (32), Steven-Lapsley et al. 2012 (25) fulfilled the inclusion and exclusion criteria for the systematic review and meta-analysis (Fig. 1 and Table II).
Fig. 1. Flow-chart of the literature search in Pubmed, PMC, and Cochrane. PMC: PubMed Central.
Table II. Summary of the 18 randomized controlled trials included.
Table II. Cont.
All studies were randomized controlled trial (RCTs) with a follow-up of between 6 weeks and 24 months, except for one study with only a 4-day follow-up. The total number of patients was 1,417 (Table II). Studies reported that there are no differences between groups on baseline measurement. Overall mean age was approximately 67.1 years (SD 2.5) and the percentage of females was 64.2%.
Interventions varied widely across studies. The specific rehabilitation programmes, which were compared with standard programmes, included water exercise (16), balance exercise (30), manual lymphatic drainage (24), neuromuscular electrical stimulation (NMES) (25, 27), comprehensive behavioural and exercise intervention (31), continuous passive motion (CPM) (15, 18, 21), sliding board (14), early high-intensity vs low intensity (26), strength exercise (23, 28, 29, 32), sling exercise (22), and fast track (19, 20). Six studies (21, 25, 26, 28, 29, 31) provided home exercises during the rehabilitation period.
The studies were subdivided into inpatient and outpatient groups (Table III)
Table III. Summary of the patient rehabilitation situation (inpatient–outpatient)
In terms of quality, the mean PEDro score of the studies was 8.7 (Table IV). All studies reported eligibility criteria except for 3 studies (14, 18, 20). Two studies did not explain their randomization strategy clearly (20, 29). Blinding assessors occurred in 9 of 18 studies, respectively (19–21, 24, 26, 29–32).
Table IV. PEDro scale included studies (n = 18)
Knee range of motion
Knee ROM was measured with a standard goniometer, and covered active flexion and extension of the knee from different positions, e.g. during seated, supine, lying and prone positions. The results compared improvement and lack of it between experimental and control groups after the rehabilitation programme ended. The active extension ROM dataset was available for 12 studies (991 patients) (14, 15, 18–22, 24–27, 32), the mean and SD of the following-up period was 204.2 days (SD 220.1). The comparison for knee extension was numerically in favour of the experimental group (EE –0.24; 95% CI –1.29 to 0.81; p = 0.65, Fig. 2). In the active extension ROM, no significant differences were found in the 11 studies between the modified and the standard rehabilitation programmes after TKA. The studies shared the same starting point for the rehabilitation programme, which was within the first 36 h after surgery, the differences were in the duration and the method used, except for one study Schache et al. (32), which started 2 weeks after the operation. One study had an equal mean result between the 2 groups, so no preference was analysed for the methods used in either the experimental or control groups (14). Five studies out of the 12 reported improvements in the ROM mean in the experimental group (19, 20, 24–26). The other studies reported improvement in the ROM mean in the control group (15, 18, 21, 22, 27, 32). Three out of these 6 studies used CPM as the main method to regain the ROM, without considering the other methods or exercises, which could be a reason for these negative results (15, 18, 2
Fig. 2. Forest plot of the knee extension comparison. SD: standard deviation; 95% CI: 95% confidence interval.
The active flexion ROM dataset was available for 13 studies (n = 1.025 patients) (14–16, 18–22, 24–27, 32). The mean and SD for the following-up period was 218.8 days (SD 220.1), where the comparison for knee flexion was numerically in favour of the control group (EE 3.33; 95% CI –0.18 to 6.83; p = 0.06, Fig. 3). In active flexion ROM, no significant differences were found in the 13 studies between modified and standard rehabilitation programmes after TKA. Eleven studies shared a starting time, which was within the first 4 days after surgery. Two studies started directly after discharge. Four studies found better mean improvement for the experimental group (18, 20–22). Two out of these 4 studies used CPM plus strength, function and walking exercises (21, 22). The third study used functional exercises (20), and the fourth used sling exercises (22). The other 9 studies showed better mean improvement for the control group. Seven studies used different methods (e.g. sliding board technique, active/passive exercises and water exercises for ROM, NMES, extra strength exercise for hip), which were added to the individual programmes (14, 16, 19, 24, 25, 27, 32). The eighth study used early high-intensity progression (26). The ninth study used CPM parallel to strength and function exercises (15). Heterogeneity was also high, at 91%.
Fig. 3. Forest plot of the knee flexion comparison. SD: standard deviation; 95% CI: 95% confidence interval.
Pain was measured in 544 patients in 6 studies using a visual analogue scale (VAS). The results were taken after the rehabilitation programme ended. The mean and SD for the follow-up period was 91.6 days (SD 56.3). The comparison of VAS was numerically in favour of the experimental group (EE –0.71; 95% CI –1.85 to 0.43; p = 0.22, Fig. 4). No significant differences were found in the 6 studies between modified and standard rehabilitation programmes after TKA. The 6 studies used visual analogue scale (VAS) and calculated the mean and SD (18–20, 22, 27, 28). There was no significant difference in the combined result. All studies had an early starting rehabilitation point, within 48 h, except one study that started one week after surgery (28). Four studies out of 6 had better mean improvement in the experimental group than in the control group (19, 22, 27, 28). One of these 4 studies used progressive strength, in parallel with ROM exercises, strength, function and walking (28). The second study used sling exercise training (22). The third study used the same combination earlier than the control group, adding extra exercises, such as transfer and active daily living exercises (19). The fourth study used neuromuscular electrical stimulation (NMES) in parallel with strength, ROM, function, and walking exercises (27). The remaining 2 studies had better improvement in the control groups (18, 20). Heterogeneity was high, at 88%.
Fig. 4. Forest plot of the visual analogue scale (VAS) comparison. SD: standard deviation; 95% CI: 95% confidence interval.
Western Ontario and McMaster Universities Osteoarthritis Index
The overall results of the WOMAC were chosen instead of 1 or 2 attributes. Eight studies with 569 patients used WOMAC to analyse pain, stiffness, and function. The mean and SD for the following-up period was 269.1 days (SD 233.1). The comparison of WOMAC resulted in a significant improvement in the experimental group (EE –2.43; 95% CI –4.71 to –0.14; p = 0.04, Fig. 5). Eight studies used a WOMAC questionnaire to collect information about pain, stiffness, and function in their patients (15, 16, 21, 22, 25–27, 30). Seven studies had an early starting point for rehabilitation, within 48 h, except one study, which started at least 2 months after surgery (30). The combined result was significant for the experimental groups. All of the studies shared the same programme components (strength, ROM, walking and function exercises). One study had significant improvement in the overall WOMAC at the end of the rehabilitation programme (30). Liao et al. (30) added balance and endurance exercises, which might explain this positive result for WOMAC in this study. Heterogeneity was moderate, at 48%.
Fig. 5. Forest plot of the Western Ontario and McMaster Universities Osteoarthritis Index (WOMAC) comparison. SD: standard deviation; 95% CI: 95% confidence interval.
6-minute walking test
The 6MWT measures the maximal distance a subject is able to walk in 6 min, and is a moderately valid indicator of submaximal and maximal aerobic capacity (r = 0.53) in patients with knee OA (33). Six studies with 437 patients used 6MWT (25, 26, 28, 29, 31, 32) . The mean and SD for the following-up period was 227.8 days (SD 111.9). All the studies had long rehabilitation programmes. The difference was in the starting point, where 4 studies started late and lasted long (28, 29, 31, 32) and the other 2 started early (25, 26). The comparison of 6MWT was numerically in favour of the control group (EE 4.34; 95% CI –20.74 to 29.41; p = 0.17, Fig. 6). The combined result showed no significant difference between groups. Heterogeneity was moderate, at 35%.
Fig. 6. Forest plot of the 6-minute walking test (6MWT) comparison. SD: standard deviation; 95% CI: 95% confidence interval.
Timed Up and Go test
The TUG test measures the time to rise from an armchair, walk 3 m, turn around, and return to sitting in the same chair without physical assistance (34). Eight studies with 584 patients included TUG (16, 23, 25–27, 29, 30, 32). The mean and SD for the following-up period by days was 239.3 (SD 108.6). Comparison of the TUG test resulted in a significant improvement in the experimental group (EE –0.65; 95% CI –1.14 to –0.17; p = 0.009; Fig. 7). Eight studies used TUG in their measurements (16, 23, 25–27, 29, 30, 32). The combined result was significant for the experimental groups. All studies had almost the same programme components, consisting of strength, ROM and walking exercises. The difference was in the starting point; 3 studies started late (29, 30, 32) and the other 5 started early (16, 23, 25–27). All studies had long rehabilitation programmes, except for one study (25). Only one study showed a lack of difference between groups (16). Five studies had non-significant improvements in the experimental group (23, 25–27, 29). One study had an equal mean result (32). One study showed significant improvement in the experimental group (30). Heterogeneity was moderate, at 52%.
Fig. 7. Forest plot of the Timed Up and Go (TUG) comparison. SD: standard deviation; 95% CI: 95% confidence interval.
The main finding of this study is that there is no specific rehabilitation method that can be recommended after TKA regardless of the time it will be applied after the operation.
Many meta-analyses have compared rehabilitation methods or compared the effect of rehabilitation programmes on the length of stay. Artz et al. (33) conducted a systematic review that found no differences in physical function and pain outcomes between physiotherapy with no supervision and home exercise with outpatient supervision in the short-term. The only difference in one study was that walking skills intervention was associated with long-term improvement in walking performance. A review by Sattler et al. (35) compared 4 different early supervised exercise therapy programmes, commencing within 48 h after TKA. The study reported that there are no significant differences between groups in the maximum knee flexion or knee society score after 6 weeks post-operation.
Regarding the movement in the knee joint, knee ROM is the main follow-up outcome after TKA, and it is believed to reflect patient progression, although it is a poor marker of implant success (13). For active knee extension and flexion ROM, comparison between standard and modified rehabilitation programmes was conducted. Active knee extension and flexion ROM were based on 12 studies with 991 patients, and 13 studies with 1,025 patients respectively. However, no significant differences were found between the standard and modified rehabilitation programmes after TKA. In addition, high heterogeneity was observed in the current meta-analyses of ROM, possible causes being the use of different measurement positions across studies and difficulties extracting data from studies, particularly in the case of active extension, where negative values can be misleading and the low reliability of the instruments employed (36). Furthermore, considering knee flexion, the programmes perhaps, missing the walking part of the programme gave this negative result, in contrast to other studies using continuous passive motion (CPM).
From these outcomes regarding both factors, knee extension and flexion, it seems that depending on CPM alone does not improve knee extension, but does improve knee flexion after TKA.
Pain is one of the most important outcomes after TKA. The persistence of pain after surgical procedures has become a major focus of interest, and its prevention now represents a challenge for caregivers as an index for the quality of healthcare (36). Pain was reported in 6 studies (18–20, 22, 27, 28). These studies used a combination of ROM, strength, function, and walking. Pain reduction post-TKA was reported in 4 different studies, each implementing a different additional method (19, 20, 27, 28). This suggests that no particular method has a unique advantage in reducing pain. This result corresponds with the result of a study by Chughtai et al. (37), that there were no clear guidelines to reduce pain while using different non-pharmacological therapy, such as NMES, transcutaneous electrical nerve stimulation (TENS) or cryotherapy.
Regarding WOMAC, the current study showed significant differences in the combined result. Six studies out of 8 reported improvements in the experimental group, 2 studies were early-short (15, 21), 3 were early-long (23, 25, 26) and one study was late-long (30). The 2 studies that reported improvement for the control group were early-short (16, 22). During the search, studies were identified that supported our findings and others contradicted it. A study by Hertog et al. (3) supported the early-long rehabilitation interval. On the other hand, in the same interval, a study by Mahomed et al. (38) demonstrated contradictory results from the study of Hertog et al. (3). Furthermore, a study by Piva et al. (39) found contradictory results from the late-long result. It seems that there is no specific method to improve WOMAC according to the time interval.
The 6MWT is one of the common tests used in studies, especially for interventions in the lower limbs (40). We found 6 studies that used 6MWT (25, 26, 28, 29, 31, 32). The studies shared the same programme components (strength, ROM, walking, and function exercises). Four out of 6 studies were late-long, and the other 2 were early-long. The result did not indicate that the starting point or the duration affect the 6MWT. This finding was supported by 2 studies, which applied different rehabilitation programmes with different starting points (41).
Finally, the TUG test is a timed test, in which participants start in a seated position in an armchair and then rise, go forward 3 m, turn around, and sit back down (29). Eight studies were found that used TUG in their trials (16, 23, 25–27, 29, 30, 32). The combined result was significant for the experimental group. As mentioned above, the studies had almost the same programme components. The difference was at the starting point. Referring to this result, we believe that the combined result is skewed, and, thus the current outcome must be considered with caution. Another interesting finding is that the starting point of the rehabilitation programmes does not seem to have any effect on the result, while the long period of rehabilitation suggests a clinical added value.
This meta-analysis has some limitations. There was a high level of heterogeneity between studies, and hence the data had to be interpreted with caution.With regard to the use of subgroup analysis to reduce heterogeneity, this was precluded by a lack of data
When comparing modified rehabilitation programmes with standard programmes post-TKA, there is no clear pattern in the combination of starting time-point and duration of rehabilitation that significantly improves clinical outcomes. Moreover, improved clinical outcomes could not be attributed solely to any particular modification to the programmes. Accordingly, a one-size-fits-all approach to modified rehabilitation programmes does not result in systematic improvement in clinical outcome.
This work was supported by the German Academic Exchange Service (DAAD), Research Grant- Doctoral programmes in Germany, under grant 57129429.
The authors have no conflicts of interest to declare.
